ANT-32000A/AS HDMI, HD-SDI & Composite Input ONVIF H.264 HD 1080P30 Video Encoder + Decoder

Product Code: ANT-32000A/AS

ANT-32000A/AS HDMI, HD-SDI & Composite Input ONVIF H.264 HD 1080P30 Video Encoder + Decoder

Product Overview

This product is EOL – please see ANT-35000A1 and ANT-35000H1 as replacements.

ANT-32000A/AS HDMI,HD-SDI & Composite Input ONVIF H.264 HD 1080P30 Video Encoder, capable of up to a maximum 1920 x 1200 at 30 frames per sec encode with dual streaming using an IP LAN ethernet connection.

The inputs are  HD-SDI, HDMI (DVI) and Composite with full ONVIF profile S control for integration with VMS software, such as Milestone / Exac etc. The inputs and outputs are provided to allow for signal bypassing or looping.

Multiple streaming formats are supported such as TCP/IP, Multicast, UDP, HTTP, SMTP, FTP, DHCP, DNS, Dynamic DNS, RTP, RTSP, SNMP.

The encoder or decoder has on board recording via USB for monitoring and litigation purposes and can be powered via 12V or PoE.

AAC and G711 two way audio is supported with analogue audio support.

RS232/485/422 2 way serial data communication, motion detection , sensor and alarm I/O.

Rack mountable with 1U rack mount kit available supporting up to 3 encoders.

Product video

Find out more about the differences between H.264 HD and H.265 HD with Les Litwin, owner of Antrica.

The Key features of ANT-32000A/AS

Learn more about the key features

Viewing

1920 x 1080 P30 Max Resolution (Legacy product please see ANT-35000A latest generation Encoder)

decoding

ONVIF VMS - Profile S H.264 Encoder or Decoder (recommend ANT-36000 as decoder)

hdmi

HDMI, HD-SDI & Composite Inputs & Outputs

conversion

TCP/IP, Multicast, UDP, HTTP, SMTP, FTP, DHCP, DNS, Dynamic DNS, RTP, RTSP, SNMP Streams Supported

multiple streams

Unicast and Multicast MPEG-TS

rackmounted

Rack mountable with 1U rack mount kit available supporting up to 3 encoders

The Key features of ANT-32000A/AS

Learn more about the key features

Viewing

1920 x 1080 P30 Max Resolution (Legacy product please see ANT-35000A latest generation Encoder)

decoding

ONVIF VMS - Profile S H.264 Encoder or Decoder (recommend ANT-36000 as decoder)

hdmi

HDMI, HD-SDI & Composite Inputs & Outputs

conversion

TCP/IP, Multicast, UDP, HTTP, SMTP, FTP, DHCP, DNS, Dynamic DNS, RTP, RTSP, SNMP Streams Supported

multiple streams

Unicast and Multicast MPEG-TS

rackmounted

Rack mountable with 1U rack mount kit available supporting up to 3 encoders

ANT-32000A/AS compatibility

Antrica products are compatible with a range of products

ANTRICA'S SPECIALIST INSIGHTS AND STEP-BY-STEP SUPPORT HELPED ME TO ENSURE I MADE THE CORRECT PRODUCT CHOICE FOR MY VIDEO ENCODING SOFTWARE. A VERY GOOD SERVICE!
Becca Pye - Chief Technology Officer
Previous slide
Next slide

What markets is this product suitable for?

Here are some of the main markets that this product is most commonly deployed in. Please be aware that this list is not exhaustive.

WORLDWIDE SPECIALIST, MANUFACTURER & SUPPLIER OF VIDEO ENCODERS & VIDEO DECODERS

Antrica specialises in Video Encoders and Decoders, offers excellent service and technical support. We supply products worldwide directly or via our Global Distributors.

Discover our FREE no-obligation Loan Scheme where you can try one of our products.

product REviews

Love your Antrica product? then why not leave a review

Reviews

There are no reviews yet.

Be the first to review “ANT-32000A/AS HDMI, HD-SDI & Composite Input ONVIF H.264 HD 1080P30 Video Encoder + Decoder”

Your email address will not be published. Required fields are marked *

0 of 0 reviews

Sorry, no reviews match your current selections

Product information and support

Find out more about this product, including features and technical specifications.
  • HDMI,HD-SDI & Composite Input
  • ONVIF H.264 HD Video Encoder
  • Up to 1920 x 1080 at 30 frames per sec encode
  • Dual streaming using an IP LAN ethernet connection
  • ONVIF profile S control for integration with VMS software, such as Milestone / Exac etc
  • The inputs and outputs allow for signal bypassing or looping
  • RTSP, MPEG-TS, RTP, RTMP over TCP and UDP
  • On board recording via USB
  • Powered via 12V or PoE
  • AAC and G711 two way audio
  • Analogue Audio Support
  • RS232/485/422 2 way serial data communication
  • Motion detection, Sensor and alarm I/O
  • Rack mountable



System Mode Encoder / Decoder
System Standards ONVIF Profile S, RTSP, RTP, MPEG-TS
System Latency >150mS (system dependant)
Video Compression H.264 (MJPEG)
Video Profile Baseline & High
Video Frame Rate 1-30 fps
Video Bit Rate 32k-10 mbps
Video Mode GOP
Video Bit Rate Control CBR, VBR
Video Min Resolution 352 x 240
Video Max Resolution 1920 x 1080
Video Number of Streams Primary 1 x H.264 / Secondary 1 x H.264 or MJPEG
Video Inputs 1 x HDMI (DVI) , 1 x HD-SDI , 1 x Composite
Video Input Combinations Any 1 Input
Video Outputs 1 x HDMI (DVI) , 1 x HD-SDI , 1 x Composite Bypass
Video Output Combinations Any 1 Output
Video On Screen Display Multi-Lingual
Audio Mode Full Duplex Stereo
Audio Compression G.711 + AAC
Audio Sample Rate G711 = 8Khz , AAC= 32/44.1/48kHz
Audio Bit Rate G711=64kbps, AAC= 64/128kb/s
Audio Streaming 2 Way Stereo
Audio Inputs Analogue Stereo Jack (1vpp)
Audio Outputs Analogue Stereo Jack (1vpp)
Network Interface 10-100 Ethernet RJ45
Network Protocols IPv4/v6, TCP, UDP, IGMP(Multicast), ICMP, DHCP,HTTP, HTTPS, RTP,RTSP, FTP, SNMP, SMTP, DNS
Network Security Password Protection, Ip Address Filtering, HTTPS
Network Configuration SDK, ONVIF, WEB
Data Type Serial 2 Way
Data Interface RS232, RS422, RS485
Data Protocol Pelco D + others
Data Alarm 2 Output + Buzzer
Data Sensor 2 Input
Event Sources Motion, Sensor Input, Client Disconnection
Event Actions Email, FTP, PTZ Preset , Alarm Control, Recording
Power Supply PoE or 12v
Power Adapter input volts AC 110-240v
Power Adapter Output Voltage 12v DC
Power Consumption 9.6w
Recording Edge Storage USB
Temperature Operating Range -10 + 50C
Physical Dimensions 134 x 125 x 37 mm
Physical Weight 563g
Physical Housing Black/Silver Aluminum
General Certifications CE , FCC, RoHS
General Software IP Finder + VMS
General Warranty 12 Months
General Remote N/A
General Reset Web or external
Control & Set Up Set Up Web Interface API Document
Control API
Upgrade Firmware Upgrade
In the Box Contents Encoder , 12v Power Supply & Lead & Fixing Kit
Power Cable/adapter 1 of either UK/US/EU/China/Aus



VideoCompressionH.264 (MJPEG)VideoProfileBaseline & HighVideoFrame Rate1- 60fps (60fps @ 1080P Res)VideoBit Rate32-25 mbpsVideoModeGOPVideoBit Rate ControlCBR, VBRVideoMin Resolution352 x 240VideoMax Resolution4096 x 2160 P24 (HDMI) or 3840 x 2160 P30 (HDMI)VideoNumber of StreamsPrimary 1 x H.264 / Secondary 3 x H.264 or MJPEGVideoInputs1 x HDMI (DVI) , 1 x 3G-SDIVideoInput CombinationsAny 1 InputVideoOutputs1 x HDMI (DVI) , 1 x 3G-SDI  BypassVideoOutput CombinationsAny 1 OutputVideoOn Screen DisplayMulti-Lingual

AudioModeFull Duplex StereoAudioCompressionG.711 + AACAudioSample RateG711 = 8Khz , AAC= 32/44.1/48kHzAudioBit RateG711=64kbps, AAC= 64/128kb/sAudioStreaming2 Way StereoAudioInputsAnalogue Stereo Jack (1vpp) or Embedded AudioAudioOutputsAnalogue Stereo Jack (1vpp) or Embedded Audio

NetworkInterface10-100 Ethernet RJ45NetworkProtocolsIPv4/v6, TCP, UDP, IGMP(Multicast), ICMP, DHCP,HTTP, HTTPS, RTP,RTSP, FTP, SNMP, SMTP,DNSNetworkSecurityPassword Protection, Ip Address Filtering, HTTPSNetworkConfigurationSDK, ONVIF, WEB

DataTypeSerial 2 WayDataInterfaceRS232, RS422, RS485DataProtocolPelco D + othersDataAlarm2 Output + BuzzerDataSensor2 Input

EventSourcesMotion, Sensor Input, Client DisconnectionEventActionsEmail, FTP, PTZ Preset , Alarm Control, Recording

PowerSupplyPoE or 12vPowerAdapter input voltsAC 110-240vPowerAdapter Output Voltage12v DCPowerConsumption12w

RecordingEdge StorageUSB

TemperatureOperating Range-10 + 50C

PhysicalDimensions133 x 125 x 32mmPhysicalWeight620gPhysicalHousingBlack Aluminum

GeneralCertificationsCE , FCC, RoHSGeneralSoftwareIP Finder + VMSGeneralWarranty12 MonthsGeneralRemoteN/AGeneralResetWeb or external

Control & Set UpSet UpWeb Interface API Document
ControlAPI
UpgradeFirmware UpgradeIn the BoxContentsEncoder , 12v Power Supply & Lead & Fixing Kit
Power Cable/adapter1 of either UK/US/EU/China/Aus



A few of the applications are:

  • For new applications please use ANT-35000A or ANT-35000H
